7S 24V Battery Charging Module PCB BMS Protection Board For 7 Series lithium LicoO2 Limn2O4 18650 battery - With Balance Function - COMMON PORT (25A)
Lifepo4 6S/7S/13S 24V 36V 48V - 25A BMS Battery Management System PCM PCB - for 6, 7 and 13 Series Lifepo4 Lithium Ion Phosphate Battery Pack for ebike erikshaw
A battery management system (BMS) is an electronic system that manages a rechargeable battery (cell or battery pack), such as by monitoring its state, calculating secondary data, reporting that data, protecting the battery, controlling its environment, and balancing it.
This protection board adopts a mature protection circuit, original special IC, 80A high current ultra-low internal resistance MOS (single MOS internal resistance as low as 6.5mΩ), and has various stable protection and discharge protection functions.
Strong compatibility: The protection board supports both the same port and split port. Supports 6-13 string lithium iron phosphate batteries. (Note: The lithium iron phosphate board cannot be used for lithium iron or polymer batteries)
Default delivery: 13S (requires other strings only need to change the wiring method) Small volume and a large current can be used in high current applications such as power tools, electric vehicles, and UPS.
NOTE: This module is only suitable for 3.2V lifepo4 or iron phosphate batteries, do not use it with lithium-ion or lithium polymer batteries
Specification:
Suitable for 6, 7 and 13 string lithium iron phosphate lifepo4 battery series combination; Module Output Voltage: 24V @6S; 36V @ 7S 48V @ 13S; Over Discharge Protection Current: 40A; Charging Current: 18A; Charging voltage: 24V @ 6S/7S; 36V to 48V @ 13S
